Product Overview
The Z-40/23 N electric articulating boom lift combines a narrow chassis with quiet AC electric drive for indoor and outdoor work on firm, level surfaces. Its compact footprint, tight turning radius and articulating jib help operators reach overhead work in aisles, near buildings and around facility obstacles.
Product Information
| Product Type | Articulating Boom Lift |
| Brand | Genie |
| Model | Z-40/23 N |
| Drive | 48V 3-phase AC drive, 2WD |
| Primary Use | Elevated access for construction, maintenance and industrial applications |
Key Features
- Narrow 4 ft 11 in chassis is designed for congested jobsites and indoor access.
- AC electric drive provides responsive operation with simplified drive-system maintenance.
- 4 ft articulating jib provides a 128° range of motion for accurate positioning.
- 30% gradeability supports practical travel around facilities and jobsite access areas.
- 180° hydraulic platform rotation improves positioning around structures.
- Solid non-marking tires support indoor and finished-floor applications.
Applications
| Facility Maintenance | Overhead service, lighting, HVAC and building maintenance. |
| Industrial Plants | Production-area access and equipment maintenance in tight spaces. |
| Warehousing | High-bay, racking and overhead utility work in narrow aisles. |
| Commercial Construction | Interior installation and finish work requiring extended reach. |
Specifications
| Maximum Working Height | 46 ft 5 in |
| Maximum Platform Height | 40 ft 5 in |
| Maximum Horizontal Reach | 22 ft 8 in |
| Maximum Up-and-Over Clearance | 21 ft 3 in |
| Platform Capacity | 500 lb |
| Platform Size | 2 ft 6 in L × 4 ft 8 in W |
| Platform Rotation | 180° |
| Jib | 4 ft articulating jib with 128° vertical range |
| Turntable Rotation | 355° |
| Tailswing | 5 in |
| Drive Speed | 4.5 mph stowed / 0.68 mph raised |
| Gradeability – Stowed | 30% |
| Tires | 22 × 7 × 17.75 in solid non-marking |
| Power | 48V DC battery system (8 × 6V, 350Ah) |
| Machine Weight | 15230 lb |
| Stowed Machine Dimensions | 257 in L × 59 in W × 78 in H |
| Standards | ANSI A92.20; CSA B354.6 |
Download Specs / Sheets
Product Summary
The Z-40/23 N provides 46 ft 5 in maximum working height with 500 lb platform capacity for professional aerial-access applications.
