Product Overview
The TZ-34/20 DC trailer-mounted boom lift combines a lightweight towable chassis with a versatile articulating boom for maintenance, construction and facility work. Its compact stowed dimensions, hydraulic outriggers and 359° non-continuous turntable rotation support efficient setup and positioning in congested or surface-sensitive work areas.
Product Information
| Product Type | Trailer-Mounted Boom Lift |
| Brand | Genie |
| Model | TZ-34/20 |
| Power | 24V DC (4 × 6V, 225Ah batteries) |
| Primary Use | Towable aerial access for construction, maintenance and facility applications |
Key Features
- 40 ft maximum working height with 18 ft 4 in horizontal reach.
- Lightweight 3,155 lb chassis supports transport and use on more sensitive surfaces.
- Hydraulic outriggers with automatic 11° leveling capability simplify setup.
- Variable-speed controls support precise boom positioning.
- Self-leveling platform helps maintain a stable work position.
- 60 mph rated towing speed supports transport between jobsites.
Applications
| Facility Maintenance | Building exterior service, lighting, signage, HVAC and general overhead maintenance. |
| Construction | Installation, finishing and repair work requiring towable elevated access. |
| Property Maintenance | Tree-adjacent work, exterior repairs and grounds-related elevated tasks. |
| Rental Fleets | Compact towable access equipment for varied customer applications. |
Specifications
| Maximum Working Height | 40 ft |
| Maximum Platform Height | 34 ft |
| Maximum Horizontal Reach | 18 ft 4 in |
| Clear Outreach | 13 ft 5 in |
| Maximum Up-and-Over Clearance | 16 ft 1 in |
| Platform Capacity | 500 lb |
| Rotating Platform Capacity | 460 lb |
| Platform Size | 26.8 in L × 44 in W |
| Platform Rotation | 90° mechanical platform rotation available |
| Turntable Rotation | 359° non-continuous |
| Outrigger Leveling Capability | 11° outrigger leveling capability |
| Maximum Towing Speed | 60 mph |
| Tongue Weight | 315 lb |
| Tires | ST 205/75 R15 |
| Power Source | 24V DC (4 × 6V, 225Ah batteries) |
| Hydraulic Tank Capacity | 2.65 gal |
| Hydraulic System Capacity | 4.5 gal |
| Machine Weight | 3155 lb |
| Stowed Machine Dimensions | 216.5 in L × 57.1 in W × 76.5 in H |
| Standards | ANSI A92.20; CSA B354.6 |
Download Specs / Sheets
Product Summary
The TZ-34/20 is a professional trailer-mounted boom lift offering 40 ft working height, 18 ft 4 in horizontal reach and 500 lb platform capacity.
